SAC-N250-250125: Arbor, Combo SP, Ø.250"x1/8 Hub, Ø.1250" Bore, Ø1/4 Shk, Ø3/8 Flg, 2.5 OAL

Login Required
16
GSI Part
5015-000108
Type
Combination
TIR
< .0002in
Standard
Inch
Tool Bore (B)
.1250in
Saw ID (D1)
.250in
Journal Thickness (L1)
.125in
(D2)
.375in
(L2)
.625in
Shank Dia. (D3)
.250in
Shank Length (L3)
1.375in
Nut Dia. (D4)
.375in
Nut Length (L4)
.375in

GenSwiss ultra precision combination arbors are made from pre hardened material and exemplify what it means to be called "Swiss Precision". The addition of the combined mill or center drill provides additional tool capacity and setup flexibility . TIR measured at less than .0002". Made in the USA.
