5002-3.0-ER-15 C30 HMP725
50
- GSI Part
- 7005-556841
- Series
- 5000
- Operation/Geometry
- Cut-Off
- Chip Breaker
- C30 Chip Breaker
- Execution
- Right Handed Standard Cut
- Coating
- HMP725
- Insert Material
- Carbide
- Width Of Cut (a)
- 3.0 mm
- Nose Radius (r)
- 0.03 mm
- Clearance (α)
- 15 Degrees
- (l)
- 22.4 mm
- Tolerance
- ±0.04
5002 C30 Cut-Off Inserts
With C30 Chip Breaker
multidec® 5000 Series provides high-performance cut-off tools that are made for sliding headstock lathes in Swiss-type CNC machines. Four chip breakers available in 1.5 mm, 2.0 mm, 3.0 mm insert widths are designed to meet the highest requirements for efficient production, even in difficult-to-machine materials. multidec® 5000 Series inserts fit the multidec® 5000 Series tool holders, based on orientation left/right/neutral, and coolant-thru vs. non-coolant-thru holders.
The 5002 Insert with C30 chip breaker delivers a fine to medium cut for cutting off without counter spindle. Available in carbide with HMP725 grade coating.
- Pressed carbide insert
- Two cutting edges per insert
- Round cutting edge
- Good surface finish and chip control
- Grade HMP725: Universal high-performance grade with high wear resistance and stable cutting edge
