CIT-GSE-2507-2x: 90° 2X Accel Spdl Drill/Mill Dbl End K12E/K16E, ER11, i/o 1:2, Pos T12-14 Top Pos
0
- GSI Part
- 5505-000249
- Machine Make
- Citizen
- Machine Model
- K12, K16
- Work Location
- Main Spindle
- Operation
- End Drilling / Milling
- Static or Live
- Live Tool
- Single Or Double Ended
- Double Ended
- Speed
- Increased 2.0X
- Max RPM
- 12000
- Tool Size
- ER11
- Holds # Of Tools
- 4
- Notes
- Position T12-14 Left
This is an accelerated end working tool holder that mounts on the back gang tool post of the Citizen K12/16E machines. It has 4 stations, each utilizing an ER11 collet for toolholding. The 1:2 gear ratio is ideal for maximizing the efficacy of micro drills and micro endmills.
