CTE-16-3.18-095250: Ti-Loc ® Mill Extension - Ø1/8", ER16 Taper, Ext. Ø9.50 x 25mm w/Stop Screw

Call for availability or request a quote now.

GSI Part: 4900-325318

ER Taper Size: ER16

Extension Length (L1): 25mm

Tool Bore Size (D1): 0.125in

Extension Diameter (D2): 9.5mm

TIR: < .0002in

Coolant Capability: No

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

GenSwiss Ti-Loc® Micro End Mill Extensions provide an excellent method of holding small shank rotary tooling in a rigid fashion that makes clearing the guide bushing or sub-spindle easy while ensuring exceptional rigidity and low TIR. A must-have for any micro milling application! Signature Series Ti-Loc® Mill Extensions are designed to work with virtually any collet or tool holder that employs the dual angle ER collet system (DIN6499). Simply insert the Ti-Loc holder into any ER nut and twist to align the locking cam profile.

Reduces Tolerance "Stacking" for low TIR <.0002in
Directly Mounts to ANY ER Taper Live or Static Tool Position
Extends the Reach of Micro-Endmills and Small Shank Rotary Tools
Enables QUICK CHANGE of tooling
Coolant Thru Capability in ER16 Sizes
