GD4-048-1.0-200-C: .48mm (.0189") OD, 1mm Shank, 2mm Flute Length, 120 Deg Point UHM20
0
- GSI Part
- 3640-000128
- Series No.
- 3640 Series
- Depth Of Cut
- 4-5 x Dia.
- Flute Dia. (mm)
- 0.48
- Flute Dia. (in)
- 0.0189
- Length Of Cut (mm)
- 2
- Length Of Cut (in)
- 0.0787
- Drill Point Angle
- 120°
- Shank Diameter (mm)
- 1
- Shank Diameter (in)
- 0.0394
- OAL
- 25
- Number Of Flutes
- 2
- Helix Angle
- 35°
"
GenSwiss Micro Drills are a cost effective solution for hard to find small diameter solid carbide micro drills & micro spotting tools. Swiss-style precision ensures maximum reliability, accuracy and finish results. When consistency of hole tolerance control is paramount, look to GenSwiss micro drills.
- Sizes From .1mm (.004in) Up To 3mm (.1181in)
- Precision Ground & Finished
- Makes Use Of Readily Available ER Collets
