CS-11-160-050D: ER11 Dbl-End Collet Sleeve Ø16 x50mm Shank w/Flat, Thru, No Stop, Mini-Nut
1
- GSI Part
- 1025-000103
- Type
- Double Ended
- ER Collet Size
- ER11
- Standard
- Metric
- Nut Type
- Mini-Nut
- Shank Diameter (D1)
- 16 mm
- Shank Length (L1)
- 50 mm
- OAL (L2)
- 77 mm
- Rear Coolant Port
- None
- Side Coolant Port
- None
- Included Fitting
- None
"
ER Style Collets are the tool holding system of choice for use in CNC machine applications. Swiss Precision
collet sleeves provide rigid & accurate holding of ID tooling. These collet sleeves feature ground shanks
and tapers. Mini nuts are used to reduce interference and to make setup and tool changing easier than collet
sleeves with hexagonal clamping nuts.
