SAT-11-3.00-064100: Arbor, Tiloc ® UP Ø3.0 x 1.0mm Hub, ER11 Shank, Flange Ø6.4x10mm

Login Required
4
GSI Part
4800-000205
ER Taper Size
ER11
TIR
< .0002in
ID of Saw (D1)
3mm
Extension Dia. (D2)
6.4mm
Journal Width (L1)
1.27mm
Extension Length (L2)
10mm
Nut Length
5mm
Thread Length
5mm
"

The Ti-Loc® Swiss Clamp Saw Arbors. This Taper-integrated small saw arbor is designed to work with virtually any collet or tool holder that employs the dual angle ER collet system (DIN6499)

• Reduces Tolerance “Stacking” for low TIR
• Directly Mounts to ANY ER Taper Live or Static Tool Position
• Increases Rigidity During Slitting Saw Operations and adds repeatable location.
• Enables QUICK CHANGE of tooling

The Ti-Loc® System works with any existing tool holder *most* ER collet clamping nuts. Simply insert the Ti-Loc holder into any ER nut and twist to align the locking cam profile.

"""
