GD4-233-3.0-1200-C: 2.33mm (.0917") OD, 3mm Shank, 12mm Flute Length, 120 Deg Point UHM20

Login Required
0
This item is sold in packs of 10
We don't have this product in stock now, items will be replenished soon and can still be ordered but will have a delivery delay.
GSI Part
3640-000313
Series No.
3640 Series
Depth Of Cut
4-5 x Dia.
Flute Dia. (mm)
2.33
Flute Dia. (in)
0.0917
Length Of Cut (mm)
12
Length Of Cut (in)
0.4724
Drill Point Angle
120°
Shank Diameter (mm)
3
Shank Diameter (in)
0.1181
OAL
38
Number Of Flutes
2
Helix Angle
35°
"

GenSwiss Micro Drills are a cost effective solution for hard to find small diameter solid carbide micro drills & micro spotting tools. Swiss-style precision ensures maximum reliability, accuracy and finish results. When consistency of hole tolerance control is paramount, look to GenSwiss micro drills.

  • Sizes From .1mm (.004in) Up To 3mm (.1181in)
  • Precision Ground & Finished
  • Makes Use Of Readily Available ER Collets
"""
