GD1-115-1.5-230-H: 1.15mm (.0453") OD, 1.5mm Shank, 2.3mm Flute Length, 120 Deg Point HiCo8

Login Required
0
This item is sold in packs of 10
We don't have this product in stock now, items will be replenished soon and can still be ordered but will have a delivery delay.
GSI Part
3610-000119
Series No.
3610 Series
Depth Of Cut
2-3 x Dia.
Flute Dia. (mm)
1.15
Flute Dia. (in)
0.0453
Length Of Cut (mm)
2.3
Length Of Cut (in)
0.0906
Drill Point Angle
120°
Shank Diameter (mm)
1.5
Shank Diameter (in)
0.0591
OAL
25
Number Of Flutes
2
Helix Angle
35°
"

GenSwiss Micro Drills are a cost effective solution for hard to find small diameter solid carbide micro drills & micro spotting tools. Swiss-style precision ensures maximum reliability, accuracy and finish results. When consistency of hole tolerance control is paramount, look to GenSwiss micro drills.

  • Sizes From .1mm (.004in) Up To 3mm (.1181in)
  • Precision Ground & Finished
  • Makes Use Of Readily Available ER Collets
"""
