CTE-32-9.52-230510: Ti-Loc ® Mill Extension - Ø9.52mm, ER32 Taper, Ext. Ø23.0 x 51mm w/Stop Screw

Login Required
0
We don't have this product in stock now, items will be replenished soon and can still be ordered but will have a delivery delay.
GSI Part
4900-651952
ER Taper Size
ER32
Extension Length (L1)
51mm
Tool Bore Size (D1)
0.375in
Extension Diameter (D2)
23mm
TIR
< .0002in
"

GenSwiss Ti-Loc® Micro End Mill Extensions provide an excellent method of holding small shank rotary tooling in a rigid fashion that makes clearing the guide bushing or sub-spindle easy while ensuring exceptional rigidity and low TIR. A must-have for any micro milling application! Signature Series  Ti-Loc® Mill Extensions are designed to work with virtually any collet or tool holder that employs the dual angle ER collet system (DIN6499).  Simply insert the Ti-Loc holder into any ER nut and twist to align the locking cam profile.

• Reduces Tolerance “Stacking” for low TIR <.0002in
• Directly Mounts to ANY ER Taper Live or Static Tool Position
• Extends the Reach of Micro-Endmills and Small Shank Rotary Tools
• Enables QUICK CHANGE of tooling
Coolant Thru Capability in ER16 Sizes

"""
